Overall Dimensions: 1500mm × 120mm × 980mm

Housing Material:

Main body: Corrosion-resistant electrolytic plate, 1.5mm thick, fine-textured black sand grain baking finish

Top cover: Aluminum alloy, 10mm thick, anodized (standard color: gold)

Upright columns: Aluminum alloy, 3mm thick, anodized (standard color: gold)

Swing Arm Material:
Option A: 10mm acrylic swing door
Option B: 10mm tempered glass

Passage Width: ≤ 1100mm

Alternative Housing Finish (Optional):

Main body: Corrosion-resistant electrolytic plate, black matte sand grain baking finish

Top cover & upright columns: Anodized aluminum alloy (standard color: space gray)

Internal Structure: Steel frame construction

Power Supply Voltage: AC220V ± 10V

Drive Motor: Brushless DC motor

Mechanism Type: Speed gate mechanism (patented design)

Service Life: 15 million consecutive open-close cycles

Infrared Sensors: 8 pairs (standard)

Operating Temperature: -35°C ~ 75°C

Relative Humidity: 0% ~ 90% (non-condensing)

Communication Interface: RS232 serial port

Passing Speed: 30 ~ 50 persons/minute (memory mode can be enabled)

Swipe-to-Pass Timeout: 10 seconds (if no one passes within 10 seconds after card swiping, the gate will automatically close; timeout duration is adjustable
