Pro Integrated Access Controller
- The Pro Integrated Access Controller is a slim intelligent card-based access control terminal for office lobbies, industrial parks, residential communities, pedestrian turnstiles, and indoor or outdoor pedestrian entrances.
- As a front-end device in an integrated access control system, it combines card identification, access control, data uploading, and fire linkage, helping system integrators, property managers, and turnstile manufacturers achieve more centralized and secure pedestrian access management.
Overview
Features & Specifications
Applications
Overview
The Pro Integrated Access Controller integrates card reading, access control, local storage, alarm input, and network communication, providing stable integrated access control capability for access control systems for office buildings and pedestrian entrance management projects.
- Door opening time after card reading is less than 0.1 seconds, with support for IC/ID cards, CPU cards, and ID card physical serial number recognition for high-frequency pedestrian access.
- Supports 100,000 whitelist records and 100,000 access logs, with TCP/IP communication for uploading access data to the server and enabling centralized group-level management.
- Standard 86-box installation size, high-strength flame-retardant ABS housing, tempered glass panel, and IP65 protection support outdoor use, with fire linkage, alarm input, and NO/NC electric lock control.
Features & Specifications
| Product Name | Pro Integrated Access Controller |
| Size | 86 x 86 x 10.5 mm |
| Power Supply | DC12V |
| Rated Power | 2.5W(MAX) |
| Working Temperature | -10°C to +65°C |
| Protection Rating | IP65 |
| Access Mode | IC card (Mifare 13.56 MHz) |
| Card Reading Distance | 0 ~ 5 cm |
| Communication Interface | RJ45 (expandable RS) |
| Access Record Quantity | 100,000 |
| Whitelist Quantity | 100,000 |
| Use Scenario | Indoor and outdoor |
Applications
Access Authentication Solution
- Pro Integrated Access Controller
